API5L 45th Edition: Specification for Line Pipe Seamless & Welded Pipe
Share This Product:
  • Delivery Condition
  • Chemical Composition
  • Chemical Composition
  • Tensile and Yield
  • Tolerances Outside Diameter

PSL

Delivery Condition

Pipe grade

PSL1

As-rolled, normalized, normalizing formed

A

As-rolled, normalizing rolled, thermomechanical rolled, thermo-mechanical formed, normalizing formed, normalized, normalized and tempered or if agreed Q&T SMLS only

B

As-rolled, normalizing rolled, thermomechanical rolled, thermo-mechanical formed, normalizing formed, normalized, normalized and tempered

X42, X46, X52, X56, X60, X65, X70

PSL 2

As-rolled

BR, X42R

Normalizing rolled, normalizing formed, normalized or normalized and tempered

BN, X42N, X46N, X52N, X56N, X60N

Quenched and tempered

BQ, X42Q, X46Q, X56Q, X60Q, X65Q, X70Q, X80Q, X90Q, X100Q

Thermomechanical rolled or thermomechanical formed

BM, X42M, X46M, X56M, X60M, X65M, X70M, X80M

Thermomechanical rolled

X90M, X100M, X120M

The suffice (R, N, Q or M) for PSL2 grades, belongs to the steel grade


Steel Grade

Mass fraction, % based on heat and product analyses a,g

C
max b

Mn
max b

P
max

S
max

V
max

Nb
max

Ti
max

Seamless Pipe

A

0.22

0.90

0.30

0.30

-

-

-

B

0.28

1.20

0.30

0.30

c,d

c,d

d

X42

0.28

1.30

0.30

0.30

d

d

d

X46

0.28

1.40

0.30

0.30

d

d

d

X52

0.28

1.40

0.30

0.30

d

d

d

X56

0.28

1.40

0.30

0.30

d

d

d

X60

0.28 e

1.40 e

0.30

0.30

f

f

f

X65

0.28 e

1.40 e

0.30

0.30

f

f

f

X70

0.28 e

1.40 e

0.30

0.30

f

f

f

Welded Pipe

A

0.22

0.90

0.30

0.30

-

-

-

B

0.26

1.2

0.30

0.30

c,d

c,d

d

X42

0.26

1.3

0.30

0.30

d

d

d

X46

0.26

1.4

0.30

0.30

d

d

d

X52

0.26

1.4

0.30

0.30

d

d

d

X56

0.26

1.4

0.30

0.30

d

d

d

X60

0.26 e

1.40 e

0.30

0.30

f

f

f

X65

0.26 e

1.45 e

0.30

0.30

f

f

f

X70

0.26e

1.65 e

0.30

0.30

f

f

f

  1. Cu ≤ = 0.50% Ni; ≤ 0.50%; Cr ≤ 0.50%; and Mo ≤ 0.15%
  2. For each reduction of 0.01% below the specified max. concentration for carbon, and increase of 0.05% above the specified max. concentration for Mn is permissible, up to a max. of 1.65% for grades ≥ B, but ≤ = X52; up to a max. of 1.75% for grades > X52, but < X70; and up to a maximum of 2.00% for X70.
  3. Unless otherwise agreed NB + V ≤ 0.06%
  4. Nb + V + TI ≤ 0.15%
  5. Unless otherwise agreed.
  6. Unless otherwise agreed, NB + V = Ti ≤ 0.15%
  7. No deliberate addition of B is permitted and the residual B ≤ 0.001%

Steel Grade

Mass fraction, % based on heat and product analyses

Carbon Equiv a

C
max b

Si
max

Mn
max b

P
max

S
max

V
max

Nb
max

Ti
max

Other

CE IIW
max

CE Pcm
max

Seamless and Welded Pipe

BR

0.24

0.40

1.20

0.025

0.015

c

c

0.04

e,l

.043

0.25

X42R

0.24

0.40

1.20

0.025

0.015

0.06

0.05

0.04

e,l

.043

0.25

BN

0.24

0.40

1.20

0.025

0.015

c

c

0.04

e,l

.043

0.25

X42N

0.24

0.40

1.20

0.025

0.015

0.06

0.05

0.04

e,l

.043

0.25

X46N

0.24

0.40

1.40

0.025

0.015

0.07

0.05

0.04

d,e,l

.043

0.25

X52N

0.24

0.45

1.40

0.025

0.015

0.10

0.05

0.04

d,e,l

.043

0.25

X56N

0.24

0.45

1.40

0.025

0.015

0.10f

0.05

0.04

d,e,l

.043

0.25

X60N

0.24f

0.45f

1.40f

0.025

0.015

0.10f

0.05f

0.04f

g,h,l

As agreed

BQ

0.18

0.45

1.40

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X42Q

0.18

0.45

1.40

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X46Q

0.18

0.45

1.40

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X52Q

0.18

0.45

1.50

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X56Q

0.18

0.45f

1.50

0.025

0.015

0.07

0.05

0.04

e,l

.043

0.25

X60Q

0.18f

0.45f

1.70f

0.025

0.015

g

g

g

h,l

.043

0.25

X65Q

0.18f

0.45f

1.70f

0.025

0.015

g

g

g

h,l

.043

0.25

X70Q

0.18f

0.45f

1.80f

0.025

0.015

g

g

g

h,l

.043

0.25

X80Q

0.18f

0.45f

1.90f

0.025

0.015

g

g

g

i,j

As agreed

X90Q

0.16f

0.45f

1.90

0.020

0.010

g

g

g

j,k

As agreed

X100Q

0.16f

0.45f

1.90

0.020

0.010

g

g

g

j,k

As agreed

Welded Pipe

BM

0.22

0.45

1.20

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X42M

0.22

0.45

1.30

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X46M

0.22

0.45

1.30

0.025

0.015

0.05

0.05

0.04

e,l

.043

0.25

X52M

0.22

0.45

1.40

0.025

0.015

d

d

d

e,l

.043

0.25

X56M

0.22

0.45f

1.40

0.025

0.015

d

d

d

e,l

.043

0.25

X60M

0.12f

0.45f

1.60f

0.025

0.015

g

g

g

h,l

.043

0.25

X65M

0.12f

0.45f

1.60f

0.025

0.015

g

g

g

h,l

.043

0.25

X70M

0.12f

0.45f

1.70f

0.025

0.015

g

g

g

h,l

.043

0.25

X80M

0.12f

0.45f

1.85f

0.025

0.015

g

g

g

i,j

.043f

0.25

X90M

0.10

0.55f

2.10f

0.020

0.010

g

g

g

i,j

-

0.25

X100M

0.10

0.55f

2.10f

0.020

0.010

g

g

g

i,j

-

0.25

  1. SMLS t>0.787”, CE limits shall be as agreed. The CEIIW limits applied fi C > 0.12% and the CEPcm limits apply if C ≤ 0.12%
  2. For each reduction of 0.01% below the specified max. concentration for carbon, and increase of 0.05% above the specified max. concentration for Mn is permissible, up to a max. of 1.65% for grades ≥ B, but ≤ = X52; up to a max. of 1.75% for grades > X52, but < X70; and up to a maximum of 2.00% for X70.
  3. Unless otherwise agreed Nb = V ≤ 0.06%
  4. Nb = V = Ti ≤ 0.15%
  5. Unless otherwise agreed, Cu ≤ 0.50%; Ni ≤ 0.30% Cr ≤ 0.30% and Mo ≤ 0.15%
  6. Unless otherwise agreed
  7. Unless otherwise agreed, Nb + V + Ti ≤ 0.15%
  8. Unless otherwise agreed, Cu ≤ 0.50% Ni ≤ 0.50% Cr ≤ 0.50% and MO ≤ 0.50%
  9. Unless otherwise agreed, Cu ≤ 0.50% Ni ≤ 1.00% Cr ≤ 0.50% and MO ≤ 0.50%
  10. B ≤ 0.004%
  11. Unless otherwise agreed, Cu ≤ 0.50% Ni ≤ 1.00% Cr ≤ 0.55% and MO ≤ 0.80%
  12. For all PSL 2 pipe grades except those grades with footnotes j noted, the following applies. Unless otherwise agreed no intentional addition of B is permitted and residual B ≤ 0.001% .

Pipe Grade

Tensile Properties - Pipe Body of SMLS and Welded Pipes PSL 1

Seam of Welded Pipe

Yield Strength a
Rt0,5 PSI Min

Tensile Strength a
Rm  PSI Min

Elongation
(in 2in Af % min)

Tensile Strength b
Rm  PSI Min

A

30,500

48,600

c

48,600

B

35,500

60,200

c

60,200

X42

42,100

60,200

c

60,200

X46

46,400

63,100

c

63,100

X52

52,200

66,700

c

66,700

X56

56,600

71,100

c

71,100

X60

60,200

75,400

c

75,400

X65

65,300

77,500

c

77,500

X70

70,300

82,700

c

82,700

a. For intermediate grade, the difference between the specified minimum tensile strength and the specified minimum yield for the pipe body shall be as given for the next higher grade.
b. For the intermediate grades, the specified minimum tensile strength for the weld seam shall be the same as determined for the body using foot note a.
c. The specified minimum elongation, Af, expressed in percent and rounded to the nearest percent, shall be determined using the following equation:
Where C is 1 940 for calculation using Si units and 625 000 for calculation using USC units
Axc   is the applicable tensile test piece cross-sectional area, expressed in square millimeters (square inches) , as follows

  • For circular cross-section test pieces, 130mm2 (0.20 in2) for 12.7 mm (0.500 in) and 8.9 mm (.350 in) diameter test pieces; and 65 mm2 (0.10 in2) for 6.4 mm (0.250in) diameter test pieces.
  • For full-section test pieces, the lesser of a) 485 mm2 (0.75 in2) and b) the cross-sectional area of the test piece, derived using the specified outside diameter and the specified wall thickness of the pipe, rounded to the nearest 10 mm2 (0.10in2)
  • For strip test pieces, the lesser of a) 485 mm2 (0.75 in2) and b) the cross-sectional area of the test piece, derived using the specified width of the test piece and the specified wall thickness of the pipe, rounded to the nearest 10 mm2 (0.10in2)

U   is the specified minimum tensile strength, expressed in megapascals (pounds per square inch)


Pipe Grade

Tensile Properties - Pipe Body of SMLS and Welded Pipes PSL 2

Seam of Welded Pipe

Yield Strength a
Rt0,5 PSI Min

Tensile Strength a
Rm  PSI Min

Ratio a,c
R10,5IRm

Elongation
(in 2in)
Af %

Tensile Strength d
Rm (psi)

Minimum

Maximum

Minimum

Maximum

Maximum

Minimum

Minimum

BR, BN,BQ,BM

35,500

65,300

60,200

95,000

0.93

f

60,200

X42,X42R,X2Q,X42M

42,100

71,800

60,200

95,000

0.93

f

60,200

X46N,X46Q,X46M

46,400

76,100

63,100

95,000

0.93

f

63,100

X52N,X52Q,X52M

52,200

76,900

66,700

110,200

0.93

f

66,700

X56N,X56Q,X56M

56,600

79,000

71,100

110,200

0.93

f

71,100

X60N,X60Q,S60M

60,200

81,900

75,400

110,200

0.93

f

75,400

X65Q,X65M

65,300

87,000

77,600

110,200

0.93

f

76,600

X70Q,X65M

70,300

92,100

82,700

110,200

0.93

f

82,700

X80Q,X80M

80,.500

102,300

90,600

119,700

0.93

f

90,600

a. For intermediate grade, refer to the full API5L specification.
b. for grades > X90 refer to the full API5L specification.
c. This limit applies for pies with D> 12.750 in
d. For intermediate grades, the specified minimum tensile strength for the weld seam shall be the same value as was determined for the pipe body using foot a.
e. for pipe requiring longitudinal testing, the maximum yield strength shall be ≤ 71,800 psi
f. The specified minimum elongation, Af, expressed in percent and rounded to the nearest percent, shall be determined using the following equation:
Where C is 1 940 for calculation using Si units and 625 000 for calculation using USC units
Axc   is the applicable tensile test piece cross-sectional area, expressed in square millimeters (square inches) , as follows

  • For circular cross-section test pieces, 130mm2 (0.20 in2) for 12.7 mm (0.500 in) and 8.9 mm (.350 in) diameter test pieces; and 65 mm2 (0.10 in2) for 6.4 mm (0.250in) diameter test pieces.
  • For full-section test pieces, the lesser of a) 485 mm2 (0.75 in2) and b) the cross-sectional area of the test piece, derived using the specified outside diameter and the specified wall thickness of the pipe, rounded to the nearest 10 mm2 (0.10in2)
  • For strip test pieces, the lesser of a) 485 mm2 (0.75 in2) and b) the cross-sectional area of the test piece, derived using the specified width of the test piece and the specified wall thickness of the pipe, rounded to the nearest 10 mm2 (0.10in2)

U   is the specified minimum tensile strength, expressed in megapascals (pounds per square inch
g. Lower values fo R10,5IRm may be specified by agreement
h. for grades > x90 refer to the full API5L specification.

Specified Outside Diameter D (in)

Diameter Tolerance, inches d

Out-of-Roundness Tolerance in

Pipe except the end a

Pipe end a,b,c

Pipe except the End a

Pipe End a,b,c

SMLS Pipe

Welded Pipe

SMLS Pipe

Welded Pipe

< 2.375

-0.031 to + 0.016

-  0.031 to + 0.016

0.048

0.036

≥2.375 to 6.625


+/- 0.0075D


-  0.016 to + 0.063

0.020D for
By agreement for

0.015D for

By agreement for

>6.625 to 24.000

+/- 0.0075D

+/- 0.0075D, but max of 0.125

+/- 0.005D, but max of 0.063

0.020D

0.015D

>24 to 56

+/- 0.01D

+/- 0.005D but max of 0.160

+/- 0.079

+/- 0.063

0.015D for but max of 0.060
For
By agreement
for

0.01D for but max of 0.500
For
By agreement
for

>56

As agreed

  1. The pipe end includes a length of 4 in ate each of the pipe extremities
  2. For SMLS pipe the tolerance apply for t≤0.984in and the tolerances for the thicker pipe shall be as agreed
  3. For expanded pipe with D≥8.625in and for non-expanded pipe, the diameter tolerance and the out-of-roundness tolerance may be determined using the calculated inside diameter or measured inside diameter rather than the specified OD.
  4. For determining compliance to diameter tolerance, the pipe diameter is defined as the circumference of the pipe in any circumferential plane divide by Pi.

Wall thickness t
inches

Tolerances a
inches

SMLS pipe b

≤ 0.157

+ 0.024 / - 0.020

  • 0.157 to < 0.948

+ 0.150t / - 0.125t

≥ 0.984

+ 0.146 or + 0.1t, whichever is the greater
- 0.120 or – 0.1t, whichever is the greater

Welded pipe c,d

≤ 0.197

+/- 0.020

> 0.197 to < 0.591

+/- 0.1t

≥ 0.591

+/- 0.060

  • If the purchase order specifies a minus tolerance for wall thickness smaller than the applicable value given in this table, the plus tolerance for wall thickness shall be increased by an amount sufficient to maintain the applicable tolerance range.
  • For pipe with D≥ 14.000 in and t≥0.984in, the wall thickness tolerance locally may exceed the plus tolerance for wall thickness by an additional 0.05t provided that the plus tolerance for mass is not exceeded.
  • The plus tolerance for wall thickens does not apply to the weld area
  • See the full API5L spec for full details
Related Product
ASTM A179
ASTM A179
ASTM A179: Standard Specification for Seamless Cold- Drawn Low-Carbon Steel Heat-Exchanger a...
Learn More
API 5L Welded
API 5L Welded
API5L 45th Edition: Specification for Line Pipe Seamless & Welded Pipe ...
Learn More
ASTM A192
ASTM A192
ASTM A192: Standard Specification For Seamless Carbon Steel Boiler Tube For High-Pressure S...
Learn More
Feedback from contact with us
If you’d like a free consultation, please start by completing the form:
Product Catalog
